Common chips:	NXP MIFARE series, Fudan series, NXP NTAG series, NXP ICODE series, SIC series, ST series
Operating frequency：	13.56MHz	Meet the standards：	ISO 14443A、ISO 15693
Memory capacity：	related to the integrated chip	Read-write distance：	Related to integrated chips
Related to integrated chips：	R/W (read-write)	Operating mode:	0～10CM
Reads and writes：	100000times	Data retention：	10 years

High frequency is a kind of RFID technology, the operating frequency is 13.56 MHz. There are ISO14443 and ISO15693 standards in the 13.56MHz frequency band. ISO14443 is commonly known as MIFARE 1 series products. After encryption, there are also two types of typeA and typeB. TypeB is mainly used for ID card, passport, UnionPay card, etc., which has a higher encryption technology. 15693 is not encrypted, mainly used in anti-counterfeiting, strong detection, strengths. ISO14443: Hmin = 1.5 A/m (Mifare); ISO15693: Hmin = 0.15A /m(I*Code). That is to say, the ISO15693 standard sensitivity is 10 times that of ISO14443, which should be one of the main differences.

features

The operating frequency is 13.56MHz, and the wavelength of this frequency is about 22m.
Wavelengths of this frequency can pass through most materials except metallic materials, but tend to reduce the reading distance.
The label needs to be more than 4mm away from the metal, and its anti-metal effect is better in several frequency bands.
Sensors usually come in the form of electronic tags.
Although the magnetic field region of this frequency drops rapidly, it produces a relatively uniform read-write region. The system has anti-collision characteristics,
You can write some data information to the tag.
the data transmission rate is faster than the low frequency, the price is not very expensive.

The main applicatio

campus, home and school entrance channel application
the application of library management system
enterprise park, shaft site, enterprise personnel attendance application
Application of anti-counterfeiting consumables
Application of tooling washing management
Large conference personnel channel system
fixed assets management system
Management and application of pharmaceutical logistics system
Intelligent shelf management
Jewelry inventory management.

Comply with international standards
